Euphoria Xpert 6″x9″ 2-Way Loudspeaker w/ BCD

Login To View Price

-

Euphoria Xpert 6″x9″ 2-Way Loudspeaker w/ BCD

Brand:
EX69NCD.

Features:

• 6″x9″ 2-Way Loudspeaker

• Neodymium Ring Magnet Assembly

• Rear Mounted Full Sized Compression Driver

• IP52 Rated Paper Cone With Treated Cloth Surround

• Die-Cast Aluminum Basket With Radial Venting

• 1.4″ (36MM) Polyester Tweeter Diaphragm

• Wide Dispersion Conical HF Waveguide

• 12dB Passive Crossover Included

Note: Sold in pairs

Specs

Resonant Frequency (fs) 78.1Hz
D.C. Voice Coil Resistance (Re) 3.2Ω
Mechanical Quality Factor (Qms) 10.75
Electrical Quality Factor (Qes) 0.35
Total Quality Factor (Qts) 0.34
Compliance Equivalent Volume (Vas) 10.6L
Mechanical Compliance (Cms) 0156 mm/N
Efficiency (1W/1M) 93.4 dB
Nominal Impedance
Power Handling 500 Watts
Dynamic Wattage 1000 Watts
Sensitivity (1w/1m) 93.4 dB
Voice Coil Diameter 2.0″ (51mm)
Mounting Depth: 4.42″ (112.30mm)
Mounting Diameter: 5.82 x 8.66″ (148mm x 220.42mm)
