The EVOX2 Line brings the latest technology in a compact design with the highest quality components. From a pioneering technology, SounDigital brought to car audio amplifiers something that had not been explored yet. The thermal coupling through RTGP system. The exclusive RTGP system (Thermal Recovery for power generation) assures SounDigital products both greater thermal efficiency and robustness with higher stability.

Specs

Power @ 12.6V @ 4Ω: 2 x 396 WRMS

Power @ 12.6V @ 2Ω: 2 x 600 WRMS

Bridge Power @ 12.6V @ 4Ω: 1 x 1200 WRMS

Operating Voltage: 8V – 16V

Current Draw (Music): 57 A

Current Draw (Max): 115 A

Recommended Fuse (Music): 60 A

Total Efficiency: 83%

Damping Factor: 200

Frequency Response (-3dB): 5Hz – 22kHz

SNR: 91dB

Crossover HPF: 45Hz – 850Hz

Crossover LPF: 45Hz – 850Hz

THD + N (10% Rated Power): 0.1%

Product Dimensions: 7.1 x 5.4 x 2.2 in

Product Dimensions: 18.1 x 13.6 x 5.5 cm

Resources

Manual
