Features:

• Signal Input: 8 High-Low Level Inputs

• Signal Output: 8 RCA Outputs

• Output Impedance: 200 Ohms

• Frequency Response: 20Hz – 20kHz +/- 0.5Db

• Input Voltage: 0.02V – 12V

• Input Impedance: 20k Ohms

• Output Voltage: Up to 8V (Unity gain 4V gets UP to 4 V out, 2 V in gets UP to 2 V out, etc.)

• THD+N: <1.0%

• Signal-to-Noise: >100 dBA (A-weighted)

• Digital Signal Processing (DSP): Speed: 147 MIPS | Precision: 32-Bit | Accumulators: 72-bit

• Digital to Analog (DAC): Precision: 24-Bit

• Dynamic Range: 108 dB

• THD+N: -98 dB

• Analog to Digital (ADC): Precision: 24-Bit

• Dynamic Range: 105 dB

• THD+N: -98 dB

• Operating Voltage: 9 – 16 VDC

• Crossover Frequency: Variable: 20 Hz to 10 kHz

• Crossover Slope: Selectable Slope: 6/12/18/24/36/48 dB/Octave

• EQ Frequency Controls: Selectable Q: 0.05 to 20.0

• Dimensions (H x W x D): 1.26″ x 4.04″ x 5.12″
