Euphoria Xpert 6.5″ Neodymium Series 2-Way Loudspeaker
-
Euphoria Xpert 6.5″ Neodymium Series 2-Way Loudspeaker
The EX6NCD features a rear mounted full sized compression drive along with a wide dispersion conical high frequency waveguide that creates crisp, full and clear sound. Also, the Neodymium Ring Magnet Assembly allows for true reverberation which means you will hear the music the way it was meant to be heard.
Features:
• 2″ (51mm) Midrange Voice Coil
• Neodymium Ring Magnet Assembly
• Rear Mounted Full Sized Compression Driver
• IP52 Rated Paper Cone With Treated Cloth Surround
• Die-Cast Aluminum Basket With Radial Venting
• 1.4″ (36mm) Polyester Tweeter Diaphragm
• Wide Dispersion Conical HF Waveguide
• 12dB Passive Crossover Included
• Protective Grills Included
Note: Sold in pairs
Specs
| Resonant Frequency (fs) | 61.2Hz |
| D.C. Voice Coil Resistance (Re) | 3.2Ω |
| Mechanical Quality Factor (Qms) | 4.82 |
| Electrical Quality Factor (Qes) | 0.32 |
| Total Quality Factor (Qts) | 0.3 |
| Compliance Equivalent Volume (Vas) | 6.3L |
| Mechanical Compliance (Cms) | 0.28 mm/N |
| Efficiency (1W/1M) | 105.7 dB |
| Nominal Impedance | 5.2Ω |
| Power Handling | 400 Watts |
| Dynamic Wattage | 800 Watts |
| Sensitivity (1w/1m) | 105.7 dB |
| Voice Coil Diameter | 2.0″ (51mm) |
| Mounting Depth: | 3.41″ (88.64mm) |
| Mounting Diameter: | 5.75″ (146mm) |
