Euphoria Xpert 8″ Midrange Speaker

Login To View Price

-

Euphoria Xpert 8″ Midrange Speaker

Brand:
EXM8SN.
UPC: 811536031815

Features:

• 2″ (51mm) Voice Coil

• Neodymium 10 Piece Radially Equalized Magnet Assembly

• IP52 Rated Paper Cone With Treated Cloth Surround

• Heavy Gauge Stamped Steel Basket

Note: Sold each

Specs

T/S PARAMETERS
Resonant Frequency (fs) 71.8Hz
D.C. Voice Coil Resistance (Re) 3.2Ω
Mechanical Quality Factor (Qms) 4.02
Electrical Quality Factor (Qes) 0.39
Total Quality Factor (Qts) 0.36
Compliance Equivalent Volume (Vas) 24.4L
Mechanical Compliance (Cms) 0.36 mm/N
Efficiency (1W/1M) 99.6 dB
ADDITIONAL SPECS
Nominal Impedance
Power Handling 300 Watts
Dynamic Wattage 600 Watts
Sensitivity (1w/1m) 99.6 dB
Voice Coil Diameter 2.0″ (51mm)
DIMENSIONS
Mounting Depth: 3.43″ (87mm)
Mounting Diameter: 7.13″ (181mm)
