Euphoria Xpert 8″ Midrange Speaker
-
Euphoria Xpert 8″ Midrange Speaker
Features:
• 2″ (51mm) Voice Coil
• Neodymium 10 Piece Radially Equalized Magnet Assembly
• IP52 Rated Paper Cone With Treated Cloth Surround
• Heavy Gauge Stamped Steel Basket
Note: Sold each
Specs
| T/S PARAMETERS | |
| Resonant Frequency (fs) | 71.8Hz |
| D.C. Voice Coil Resistance (Re) | 3.2Ω |
| Mechanical Quality Factor (Qms) | 4.02 |
| Electrical Quality Factor (Qes) | 0.39 |
| Total Quality Factor (Qts) | 0.36 |
| Compliance Equivalent Volume (Vas) | 24.4L |
| Mechanical Compliance (Cms) | 0.36 mm/N |
| Efficiency (1W/1M) | 99.6 dB |
| ADDITIONAL SPECS | |
| Nominal Impedance | 4Ω |
| Power Handling | 300 Watts |
| Dynamic Wattage | 600 Watts |
| Sensitivity (1w/1m) | 99.6 dB |
| Voice Coil Diameter | 2.0″ (51mm) |
| DIMENSIONS | |
| Mounting Depth: | 3.43″ (87mm) |
| Mounting Diameter: | 7.13″ (181mm) |
