DB Drive WDX1000.1 Mono Class D Amplifier
-
DB Drive WDX1000.1 Mono Class D Amplifier
Features:
• Class “D” Circuitry
• Direct Connect Speaker Terminals
• 4 Gauge Power Wire Input
• CHM- Collective Heat Management
• ACT – Adaptive Crossover Technology
• SESI – Signal Evaluation Status Indicator
• APC – Audio Protection Circuit
Specs
| Rated Power @ 14.4 Volts | 1 x 1000 Watts @ 1Ω |
| 1 x 500 Watts @ 2Ω | |
| 1 x 250 Watts @ 4Ω | |
| Low Level Input | 6V – 0.2V |
| S/N Ratio | <95 dB |
| High Pass Filter (@ 12dB Slope) | Variable 40HZ ~ 10KHz |
| Variable Low Pass Filter (@ 12dB Slope) | 15Hz ~ 1KHz |
| Bass Boost | 0dB ~ 12dB |
| Working Voltage | 12-15 Volts |
| Length | 9″ |
| Width | 5.50″ |
| Height | 2.38″ |
