Features:
• 4 Channel full range class D circuitry
• SESI – Signal Evaluation Status Indicator
• ACT- Adaptive Crossover Technology
• High-efficiency Full Range Class D Technology
• Direct Connect Speaker Terminals
• Large Gauge Power Wire Inputs
• APC – Audio Protection Circuit
Specs
GENERAL SPECIFICATIONS |
|
Rated Power @ 14.4 Volts |
4 x 450 Watts @ 4Ω |
Dynamic Power Handling |
4 x 900 Watts @ 2Ω |
|
2 x 1800 Watts @ 4Ω Bridged |
PARAMETERS |
|
Frequency Response |
10-24KHz |
S/N Ratio |
<85dB |
Working Voltage |
10-16 Volts |
Damping Factor |
100dB |
Low Level Input |
6V – 0.2V |
Ch 1/2 High Pass Filter Variable |
20Hz – 8KHz |
Ch 1/2 Low Pass Filter Variable |
50Hz – 8KHz |
Ch 3/4 High Pass Filter Variable |
20Hz – 8KHz |
Ch 3/4 Low Pass Filter Variable |
50Hz – 8KHz |
Minimum working Impedance |
2 Ohm Stereo |
Length |
9.84″ (250mm) |
Width |
4.68″ (119mm) |
Height |
2.04″ (52mm) |
